All Products  ➞ Threaded Inserts ➞ Bondsert™ ➞ Bondsert Stainless Steel ➞ Stainless Steel Heavy Wall UNC / UNF

10G x 32 UNF - 3/8" x 16 UNF 303 SS Heavy Wall Bondsert

Part Number:3334-10GHWSS
Brand:Bondsert
Barcode:9326518153153
External Thread (inch):3/8-16
Insert Material:303 Stainless Steel
External Thread:3/8-16
External Thread Class:2B
Internal Thread:10-32
Internal Thread Class:2B
Drive Tool P/N:3300-2

Specifications

About this item:
  • 10G x 32 UNF - 3/8" x 16 UNF 303 SS Heavy Wall Bondsert
  • Bondsert Threaded Inserts provide a stronger fastener assembly in soft materials such as aluminium, magnesium and even cast iron.
  • They can be used for repairing stripped threads, and for use in creating stronger threads in original equipment.
  • External threads are manufactured with standard size and pitch to permit the use of standard drills and taps.
  • The inserts can be installed with a screwdriver, bolt/jam nut, or power drive tool.
  • Bondsert Threaded Inserts are vibration resistant.
  • Within minutes of installation, the micro-encapsulated adhesive begins to set, and the newly installed inserts are fastener-ready within 5 minutes and will not back out.
  • The adhesive seals against liquids and gases up to 6,000 psi when fully cured after 72 hours.
